8kw steel plate laser cutting machine for sale

Release Time:2022-08-02

Read:

Product application
Fiber laser cutting machine is professionally used for dry cutting of various thin metal sheets, and can also cut aluminum alloy full-sheet galvanized sheet, electrolytic sheet, silicon steel, titanium alloy, galvanized sheet, thin brass sheet and other metal materials. Mainly used in sheet metal processing, metal cutting, billboard making, electrical switch manufacturing, elevator manufacturing, household appliances manufacturing, kitchenware manufacturing, tool processing and other machinery manufacturing and processing industries.

Technical parameter

Working area	3000*1500mm
Laser type	IPG/Nlight/Raycus
Laser power	3000w/4000w/6000w/8000w (Optional)
Transmission system	Gantry double-drive system
Lubrication system	Full-automatic
Maximum speed	120m/min
Maximum accelerated speed	1.2 G
Position accuracy	±0.05mm/1000mm
Reposition accuracy	±0.03mm/1000mm
Compatible formats Working environment Temp	PLT/DXF/AI/CAD etc 0-40℃, Humidity: ≤ 80%, No condensation
Total power	Around 25KW
Power supply	Triphase 380V/50Hz/60Hz
Net dimension	10600mm3470mm1875mm

Advantage of the metal fiber laser cutting machine
1. It is simpler to keep the workpiece in the correct position, the short time obtained by laser cutting does not take long and is very precise. The entire cutting interaction is easily completed in less time than traditional scissors.
2. When the segment is delivered, the workpiece does not immediately come into contact with the cutting device, thus reducing the risk of contaminating the material.
3. In usual cutting measurements, the warmth created during cutting usually softens the material. In laser cutting, there are very few warm areas, reducing the chance of material warping.

Contact us
If you have any questions, please contact me freely.
Looking forward to our cooperation in the future.
My Email is Sabrina@baiweilaser.com
